Forging of titanium ball valve

Product features

Titanium floating ball valve ball is floating, under the effect of medium pressure, the fitness ball produce certain displacement and compression at the outlet seal surface, guarantee the outlet seal.

1, titanium floating ball valve small flow resistance, ball valve are all valve class a kind of fluid resistance is small, even reducing ball valve, the fluid resistance is small.

2, quick and convenient switch, as long as the body rotate 90 °, to complete the ball valve fully open or close the action, it is easy to realize rapid opening and closing.

3, sealed performance is good. Titanium ball valve seat (ring) generally use the elastic materials such as PTFE teflon, easy to guarantee the seal, and titanium ball valve sealing force with medium pressure increases.

4, titanium floating ball valves can realize automatic control and remote control, configurable electric actuator, pneumatic equipment, hydraulic device.

5, titanium floating ball valve channel level off is smooth, not easy to deposit medium, can carry out pigging pass the ball.

specification

Pressure rating: PN1.6-10.0 MpaClass150-600 lb

Nominal diameter: DN15 - DN250 1/2 "- 10"

Driving mode: handle, worm gear and worm, pneumatic, hydraulic, electric

Titanium corresponding floating ball valve type: Q41F - 16 Ti, Ti Q41F - 25, Q41F - 40 Ti, Q41F - 64 Ti, Ti, Q41F Q41F - 100-150 lb (Ti), Q41F - 300 lb (Ti), Q41F - 600 lb (Ti), Q41F - 16 A, 25 A, Q41F Q41F - - A, Q41F 40-64 A, 100 A, Q41F Q41F - - 150 lb and Q41F - 300 lb (A) (A), Q41F - 600 lb (A), Q341F - 16 Ti, Ti Q341F - 25, Q341F - 40 Ti, Q341F - 64 Ti, Ti, Q341F Q341F - 100-150 lb (Ti), Q341F - 300 lb (Ti), Q341F - 600 lb (Ti), Q341F - 16 A, 25 A, Q341F Q341F - - A, 40 Q341F - 64 - A, A, Q341F Q341F - 100-100 lb (A), Q341F - 300 lb (A), Q341F - 600 lb (A)

Applicable medium: oxidation corrosion medium.

The technical specification

Design standards: GB/T12237, API6D, ASME B16.34

Structure length: GB/T12221, API6D, ASME B16.10

Connecting flange: HG, GB, JB, API, ANSI, ISO, BS, DIN, NF, JIS

Test standard: JB/T9092, GB/T13927, API6D, API598

The main body material

Body and bonnet: TA1, TA2, TA10, Gr2, Gr3

Ball: TA1, TA2, TA10, Gr2, Gr3

Stem: TA1, TA2, TA10, TC4, Gr2, Gr3, Gr5

Seal: PTFE, RPTFE, PPL, PEEK...
